Home Parts & pieces Extended adapter M12x1.5 to 7/16 UNF

Extended adapter M12x1.5 to 7/16 UNF

Extended adapter M12x1.5 to 7/16 UNF Extended adapter M12x1.5 to 7/16 UNF
Extended adapter M12x1.5 to 7/16 UNF Extended adapter M12x1.5 to 7/16 UNF
Extended adapter M12x1.5 to 7/16 UNF
Brass adapter M12 to 7/16 UNF. Special brass adapter to convert M12x1.5 (EU) to 7/16-24 UNF (US). Extended adapter M12x1.5 to 7/16 UNF.

Product number

CPL-GRNW-LONG M12M-716F

Default delivery time

2-3 work days

€ 13,50
Price per unit
Quantity:
Order


Extended reduction M12x1.5 to 7/16-24

Special brass adapter Hadley air horn with M12 connection. This adapter can be used to connect American 7/16-24 UNF couplings.
This gradient can be used as an extender, but can of course also be shortened.

This adapter has an M12x1.5 (EU) male thread and extends to a 7/16-24 UNF female thread.

This adapter is made entirely of brass.

So you can screw the adapter (or adapter) into an M12x1.5 input and connect a male coupling with 7/16-24 UNF thread.

Total length: 85mm
Length M12x1.5: 65mm
Hexagon length: : 20 mm

Abbreviations :

M12x1.5: European metric thread.
7/1624 UNF: American fine wire


More information about hose sizes and threads can be found here: About Threads
Shape
Adapter
Thread (A)
M12x1.5 (M)
Material
Brass
Max pressure
15 bar
Made in
The Netherlands
